Gigabyte PG5 1000W PCIe ATX Desktop Power Supply
- PCIe 5.0 Compatible Power Supply
- PCIe 5.0 12VHPWR 600W Support
- 1000W Continuous Power
- 80 Plus Gold Certification
- Cybenetics Platinum Efficiency Rating (22PS2008A)
- Cybenetics Standard Plus Noise Rating
- 90% Efficient At Typical Loads
- Length: 150mm
- 120mm Hydraulic Bearing Fan
- Compact Design with Smart Fan Control
- Intel ATX 12V 2.31 Specification
- Active PFC, OVP, OPP, SCP, UVP, OCP, OTP Protections
- Main Japanese Capacitors
- Fully Modular Design
- 10 Year Warranty
R3,018.00 incl vat
Sold Out
| SPECIFICATIONS | |
| Brand | Gigabyte |
| Series | UD (Ultra Durable) PCIe 5.0 Power Supply Unit Series |
| Model | GP-UD1000GM PG5 |
| Type | ATX |
| Maximum Power | 1000W |
| Fan Size | 120mm |
| Fan Type | Hydraulic Fluid Bearing |
| Performance | |
| Hold Up Time | >16ms |
| Power Good Signal | 100-150ms |
| Protections | OVP, OPP, SCP, UVP, OCP, OTP |
| PFC | Active, >0.9 Typical |
| Efficiency | 80 Plus Gold, 90% Efficiency At Typical Load |
| Ratings | 80 Plus Gold Certified |
| Cybenetics Platinum Efficiency Rating (22PS2008A) | |
| Cybenetics Standard Plus Noise Rating | |
| MTBF | >100,000 Hours |
| Power Outputs | |
| 3.3V | 25A Maximum (125W Shared) |
| 5.0V | 25A Maximum (125W Shared) |
| 12V | 83.3A Maximum (1000W Shared) |
| 12VHPWR | 55A Maximum (1000W Shared) |
| -12V | 0.3A (3.6W) |
| 5Vsb | 3.0A (15W) |
| Total Power Output | 1000W |
| Connectors | |
| ATX 24-Pin | 1x Single-head 610mm Flat cable |
| EPS 12V 8-Pin | 1x Twin-head 800mm (600mm, 200mm) EPS 8-Pin Flat cable |
| 12VHPWR | 1x Single-head 700mm 12VHPWR Flat cable |
| 8-Pin PCIe | 2x Twin-head 750mm (600mm, 150mm) PCI PEG Flat cables |
| SATA | 2x Four-head 1050mm (600mm, 150mm x3) SATA Flat cables |
| Peripheral (Molex, Floppy) | 1x Four-head 890mm (500mm, 120mm x2, 150mm) Molex 4-Pin Peripheral Flat Cable |
| General | |
| Dimensions | 150 x 140 x 86mm (L x W x H) |
| Weight | 1.61kg |
| Warranty Information | |
| Warranty | 10 Year Warranty |
