Features:

• Freely tilting allows easy TV angle adjustment
• Super slim design sits just 20.5mm from wall to complement the sleek look of ultra-thin TVs
• Security screws hold TV securely in the wall plate Security screws hold TV securely in the wall plate
• Open architecture provides superior ventilation and easy access for wiring.
• Lateral shift allows TV to slide left and right for perfect.
• Simple construction ensures a quick and easy installation.

Specifications:

• Screen Size Support; 23” to 42”
• Weight Support: up to 35kg’s
• VESA Compatible 50×50, 75×75, 100×100, 200×100, max: 200×200
• 20.5mm wall to TV distance
• RoHS certified
• Material: Steel
• Metal Sheet Thickness: Wall Plate THK=1.4mm cold-rolled sheet
• Bracket Arm THK=1.4mm cold-rolled sheet
• Wall Plate THK=0.055″ cold-rolled sheet
• Bracket Arm THK=0.055″ cold-rolled sheet
• Surface Finish: Powder Coating
• Strength Tested: 4 Times Approved
• Profile: 20.5mm (0.81″)
• Tilt Range: 0°?-8°
• Screen Freely Tilting: Yes
• Installation: Solid Wall
• Panel Type: Detachable Panel
• Wall Plate Type: Fixed Wall Plate
• Cable Management: No

Please Note:
• Please let a certified technician mount it for you.
• Make sure you find out the weight and mounting hole distance of your TV before mounting.
• Have a spirit level, ruler, pencil, screw drivers and the appropriate drill set before mounting.
• Measurements and instructions are found at the back of the package.
• Please make sure you use the correctly labelled screws when mounting.
• Please check that the mount if firmly mounted before installing your TV on it.

Product Code: BRK-KL22-22T

What’s in the box
1 x Main Frame,
2 x Frame Arms with hooks
2 x Screw Packs.
